| Protection Level | IP55 (Outdoor Ready) | Barrier Open/Close Time | 0.2 s (High Speed) |
| Barrier Motor | Baroxon Motor sin escobillas | Access Control Type | ESD System, Reconocimiento facial, Código QR, Tarjeta IC, Huella dactilar, Tarjeta RFID |
| Turnstile Function | Anti-Pinch, Anti-cola, Collision Avoidance, Counting Function | Operation Direction | 2-Way (Bidirectional) |
| Communication Interface | RS485 | Material | SUS 304 Acero inoxidable |
| Brand Name | Baroxon | Model Number | Ba-1116 |
| Power Supply | 60W (Low Consumption) | Size | L1500*W160*H980mm (Personalizable) |
| Channel Frame | SUS 304 (1.3mm thickness) | Pass Speed | 30-45 persons/minute |
| Door Wing Material | 10mm Tempered Glass / Acrylic | Infrared Logarithm | 6 Pairs (Outdoor Support) |
| MCBF | 5 Million Cycles | Operating Temperature | -25℃~60℃ |
◆ Premium SUS304 Stainless Steel: Corrosion-resistant and wear-resistant material with industry-standard thickness, perfectly suited for the high-humidity tropical climate of Singapore.
◆ Triple Anti-Pinch Technology: Combines cutting-edge Infrared Anti-Clip, Mechanical Anti-Clip physical protection, and Current Detection Collision Avoidance to ensure absolute safety for users passing through the gate.
◆ Advanced Logical Control: Supported by a multi-point infrared sensor matrix to block illegal entry attempts such as tailgating and counter-flow intrusion.
◆ Intelligent Voice Broadcast: Interactive voice module to enhance mobility efficiency and orderliness in pedestrian traffic flow.
◆ Tri-Color LED Indicator: Elegant three-color LED status lights (Blue, Green, Red) serving as visual guides for access authorization status.
◆ Fire Escape Integration: Direct interconnectivity with building emergency systems via a fire escape interface to open gates automatically during evacuation.
◆ Customizable Pass Speed: Flexible configuration for opening/closing response times to optimize operations in public areas like MRT stations, airports, or factory checkpoints.
