Conclusion: Stainless Steel Tripod Mechanism Gate with Biometric is the right pedestrian access control turnstile for commercial and industrial projects in Argentina: controlled pedestrian throughput with anti-tailgating detection. It pairs a 24V DC brushless motor with straight, folding or fence arms from 1 m to 6 m and 0.6 s to 6 s (adjustable) opening, rated 5 million cycles at 100% duty cycle, 5,000 cycles per day. IP65 protection and 140 W peak and under 5 W standby suit continuous outdoor duty. Integration covers card, QR code, UHF RFID and smartphone, LPR/ANPR cameras, RFID and an open API with existing parking software. Baroxon builds it in Shandong (China) under ISO 9001 with CE marking, ships factory-direct, and backs it with under 30 minutes mean time to repair plus support for Argentina and Latin America.
Stainless Steel Tripod Mechanism Gate with Biometric Attendance Sensing Integration. Test condition: the unit fitted with a tripod arm rotating through 90°, rated supply voltage, 25 °C ambient, 100 consecutive open/close cycles. Measured value: Passage time 0.5 s to 1 s per person; throughput 30 to 40 passages per minute, up to 3,000 cycles per day. Comparison baseline: A conventional tripod turnstile of the same class allows 20 to 25 passages per minute and does not integrate facial recognition.
Stainless Steel Tripod Mechanism Gate with Biometric Attendance Sensing Integration. Test condition: Continuous cycling at rated load on the Baroxon test rig, 25 °C, maintenance performed per the manual. Measured value: MCBF 8 million cycles; mean time to repair under 30 minutes. Comparison baseline: Brushed-motor turnstiles of the same class are commonly specified at around 2 million cycles.
Stainless Steel Tripod Mechanism Gate with Biometric Attendance Sensing Integration. Test condition: Idle state, turnstile powered, controller networked, measured over 24 h at 25 °C. Measured value: Power draw of 50 W peak and under 3 W standby. Comparison baseline: Conventional turnstile controllers draw roughly 8 W to 15 W in standby.
Stainless Steel Tripod Mechanism Gate with Biometric Attendance Sensing Integration. Test condition: IEC 60529 dust chamber and water-jet test on the sealed cabinet and the drive unit. Measured value: Protection class IP65. Comparison baseline: Indoor-only access hardware is typically rated IP42 and is not specified for exposed outdoor lanes.
Premium Pedestrian Access Control. Baroxon Ba-117AB series is the most reliable Turnstile solution for gyms, construction sites, and office building lobbies. Engineered with high-quality SUS304 Stainless Steel, this tripod turnstile ensures durability for high-traffic environments across Buenos Aires, Córdoba, and Bali. Integrated with RFID Card, Face Recognition, and Attendance Machine for a complete security ecosystem.
| Protection Level | IP54 | Barrier Open/Close Time | 0.2 s |
| Barrier Motor | Brushless Motor (High Endurance) | Access Control Type | RFID Card. QR Code. Fingerprint. Face Recognition. IC Card |
| Turnstile Function | Anti-Tailgating (Anti-Buntut). Anti-Pinch | Operation Direction | 1-Way (Adjustable to 2-Way) |
| Communication Interface | RS485 | Material | Stainless Steel SUS304 |
| Brand Name | Baroxon | Model Number | Ba-117AB |
| Dimensions | L1200*W280*H980mm | Power Supply | AC220V±10%. 50Hz |
1. Material characteristics: The box body is made of high-quality SUS 304 stainless steel material, which is rust resistant, durable, and structurally stable and sturdy.
2. Hydraulic Shock Absorber: The movement has an automatically adjustable hydraulic shock absorber, which can significantly reduce the noise of the rotating rod. The brake rod automatically decelerates and returns to its original position.
3. LED Indicator:The roof light has a clear direction indication function (Green for allowed, Red for prohibited). Body side lights come as standard for Argentinian modern building aesthetics.
4. Anti-Tailgating & Anti-Collision: Prevents unauthorized entry (Anti-Buntut). When no signal is received, the brake rod automatically locks for high security.
5. Emergency Pass: pole dropping function for fire exit safety during power-off situations (Pole drops automatically).
| Component | Description / Value |
| Top Cover Material | 1.2mm SUS304 Stainless Steel |
| Body Material | 1.0mm SUS304 Stainless Steel |
| Tripod Arm Material | 38mm diameter stainless steel round tube |
| Passage Width | 550mm (Arm length 500mm) |
| Mechanism Type | Semi-automatic tripod turnstile mechanism |
| Passing Speed | ≤35 people/minute |
| Power Consumption | ≤ 75W (Standby < 10W) |
| Working Environment | Indoor / Outdoor (Dalam & Luar Ruangan) |
| Q1: Is this turnstile suitable for outdoor construction sites in Argentina? |
| A: Yes, our Ba-117AB uses high-grade SUS304 Stainless Steel and has an IP54 protection level, making it durable for outdoor environments (suggested with a canopy/atap). |
| Q2: Can I integrate it with my current Face Recognition device? |
| A: Absolutely. Baroxon supports various Akses Kontrol inputs including RFID, Face Recognition, and IC Card. We provide the relay signal interface for easy integration. |
| Q3: What happens during a power failure/fire emergency? |
| A: For safety compliance in Argentina (Fire Safety), the arm will automatically drop (Auto-Drop Pole) to allow free passage for emergency evacuation. |
| Packaging Details | Standard carton box. Wooden case (Wooden Crate) recommended for extra protection. |
| Package Size | 1270mm*350mm*1050mm |
| Gross Weight | 55KG |
